BERA® Grass Fix Eco 2017-11-01T18:08:29+00:00

What is BERA® Grass Fix Eco?

BERA® Grass Fix Eco is a versatile yet strong method to reinforce your green areas. Most grass pavers made of concrete, tend to heat up causing the grass to dry out and scorch, creating discomfort for bare foot pedestrians. Due to the low thermal conductive properties of HDPE, BERA® Grass Fix Eco solves this problem. No more discomfort! Furthermore expansion of less than 0.29% per meter length at a temperature of 50 ˚C due to sun exposure, is normal.

Applications:

  • Landscaping urban areas
  • Residential gardens
  • Parking and grass driveways
  • Paths and service access routes

Features and benefits of BERA® Grass Fix Eco:

  • Versatile modules with anti-slip nods, 60 x 40 cm with a honeycomb structure depth of 3.1 cm
  • Easily cut around obstacles such as trees, shrubs or fences
  • Fully porous, yet retaining humidity for the growth of the grass
  • Anchored and interlocked sheets provide a stable base
  • Strength empty up to 115 T/m2 – DIN 14090
  • European Union manufacturing following directives of ISO9001 and 14001
  • Environmentally friendly solution, made of recycled HDPE and fully recyclable
TECHNICAL SPECIFICATIONS
GENERAL
Material Recycled High Density PolyEthylene (HDPE)
Manufacturing technique High precision injection moulding
Manufacturing standards ISO9001, ISO14001
Application standards DIN 14090
UV and frost resistance Included
Colour Green or Anthracite
Cell structure Honeycomb
Anchors Integrated
Interlocking Quick locking
PHYSICAL DATA
Produkt-Type 50.50 60.40
Standard sheet size 50 x 50 x 3.8 cm 56 x 38 x 3.1 cm
Standard size incl. anchor height 50 x 50 x 7.3 cm 56 x 38 x 6.6 cm
Tolerance dimensions +/- 2% +/- 2%
Surface per sheet 0.25 m² 0.211 m²
Quantity per m² 4 4.73
Quantity of sheets /m² per pallet 240 sheets / 60 m2 300 sheets / 63.4 m2
 Weight per sheet, approx. 1.2 kg 0.9 kg
Weight per m² , approx. 4.8 kg 4.3 kg
Strength, empty DIN EN ESO 604 150 T/m² 115 T/m²
Thermal expansion at 50°C 0.29 % 0.29 %
EAN Code 4003412033211 4003412084183
*All data is subject to change without prior notice by the manufacturer
