What is BERA® Grass Fix Eco+ HD?

BERA® Grass Fix Eco+ HD is an ultra-strong method to reinforce your green areas. It is an unique product to be implemented in the stabilization of grassed area’s such as road embankments, overflow parkings and emergency roads. Most grass pavers made of concrete, tend to heat up causing the grass to dry out and scorch, creating discomfort for bare foot pedestrians. Due to the low thermal conductive properties of HDPE, BERA® Grass Fix Eco+ HD solves this problem. Furthermore the sheets are designed with water collection at the bottom for better moisture control of the soil. Integrated interlocking is provided.

Applications in landscaping:

  • Landscaping greened urban areas
  • Erosion control for slopes
  • Parking and grass driveways
  • Road, river and pond embankments
  • Emergency and service access routes
  • Railway and tram tracks
  • Camping and resorts

Applications in agriculture:

  • Farm access roads
  • Cattle and feeding areas
  • Soil reinforcement and erosion control

Features and benefits of BERA® Grass Fix Eco+ HD:

  • Environmentally friendly solution, fully recyclable strong stabilization product
  • Strength empty up to 270 T/m2 for all heavy duty purposes, filled depending on material use, up to 800 T/m2
  • Versatile honeycomb modules with integrated water channels, sheet height 6 cm
  • Secure interlocks keeping sheets perfectly together, providing a stable base for all trafficked area’s
  • Fully porous, yet retaining additional humidity for the growth of the grass
  • Easily cut around obstacles such as trees, shrubs or fences
  • European Union manufacturing following directives of REACH, ISO9001 and 14001



BERA® Grass Fix Eco+ HD is EPD certified.

EPD Document

TECHNICAL SPECIFICATIONS
GENERAL
Material 100% recycled HDPE
Manufacturing technique High precision injection moulding
Manufacturing standards REACH, ISO9001, IATF 16949
Application standards DIN 14090
UV and frost resistance Included
Colour black or green
Cell structure Honeycomb, diameter 5.5 cm
Water accumulation Included
Interlocking Included
PHYSICAL DATA
Standard size incl. anchor height 55 x 38 x 5.1 cm
Tolerance dimensions +/- 2%
Surface per sheet 0.215 m²
Quantity per m² 4.65
Weight per sheet, approx. 1.75 kg
Weight per m² , approx. 8.1 kg
Strength, empty EN 124-1:2017 >270 T/m²
Strength, filled depending upon fill up to 800 T/m2
PACKING
Per pallet 68 pieces = 14.62 m2
Pallet dimensions 120 x 80 x 117 cm
Weight 134 kg
*All data is subject to change without prior notice by the manufacturer
