What is BERA® Grass Fix Eco+?

BERA® Grass Fix Eco+ is a versatile yet strong method to reinforce your green areas. It is an unique ‘circular’ product to be implemented in the stabilization of grassed area’s such as overflow parkings and emergency roads. Most grass pavers made of concrete, tend to heat up causing the grass to dry out and scorch, creating discomfort for bare foot pedestrians. Due to the low thermal conductive properties of HDPE, BERA® Grass Fix Eco+ solves this problem. Furthermore an integrated absorption system for limited thermal expansion is provided for as a part of the secure interlocking.

Applications:

  • Landscaping greened urban areas
  • Residential gardens
  • Parking and grass driveways
  • Paths and service access routes
  • Paddocks and other equestrian area’s

Features and benefits of BERA® Grass Fix Eco+:

  • Environmentally friendly solution, fully circular process including ‘in-house’ household waste collection, separation, cleaning and processing into a fully recyclable strong stabilization product
  • Strength empty up to 170 T/m2 for truck access
  • Versatile honeycomb modules with anti-slip nods, 55 x 38 cm, depth 3.2 cm
  • Secure interlocks keeping sheets perfectly together, providing a stable base for all trafficked area’s
  • Anchors at the bottom of each sheet preventing shifting of the sheets
  • Fully porous, yet retaining humidity for the growth of the grass
  • Easily cut around obstacles such as trees, shrubs or fences
  • Fully porous, yet retaining humidity for the growth of the grass
  • European Union manufacturing following directives of REACH, ISO9001 and 14001
TECHNICAL SPECIFICATIONS
GENERAL
Material Recycled High Density PolyEthylene (HDPE)
Manufacturing technique High precision injection moulding
Manufacturing standards REACH, ISO9001, ISO14001
Application standards DIN 14090
UV and frost resistance Included
Colour Green or Grey
Cell structure Honeycomb
Anchors Integrated
Interlocking Secured interlocking
PHYSICAL DATA
Standard sheet size 55 x 38 x 3.2 cm
Standard size incl. anchor height 55 x 38 x 5.1 cm
Tolerance dimensions +/- 2%
Surface per sheet 0.21 m²
Quantity per m² 4.76
Quantity of sheets /m² per pallet 140 sheets / 29.4 m2
 Weight per sheet, approx. 0.9 kg
Weight per m² , approx. 4.3 kg
Strength, empty EN 124-1:2017 170 T/m²
Thermal expansion at 50°C 1 %
*All data is subject to change without prior notice by the manufacturer
